fertilizer production machine from China manufacturer - Qinhuangdao Beidou Automatic Control Equipment Co., Ltd.

Price:	80000.0~100000.0 USD
Payment Terms:	T/T
Place of Origin:	Hebei, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: BPHB-6604

Production Capacity: 100 set/year

Delivery Date: 45 days after order confirm...

Machine Type: Mixer

color: gray

Means of Transport: Ocean

Packing: wood container

Product Type: Fertilizer

Brand Name: Beidou

1. Production capacity of 10 tons per hour
2. Diamention: 1800*300*540mm
3. HIgh degree of precision

Model: BPHB-6604
Special fertilizer production machine

Complet plants.

Per/bag.

Voltage: 380VAC.

Control by PLC

Functions and features

1. Small floor space and low power consumption (power of whole set equipment less than 15kg)

2. Industry grade stainless steel used in main engine and high-performance industrial gauge (Japanese F701 gauge) used in control system, which is appropriate for severe environment including cold weather and moist weather.

3. Magnitude 2 quake free, multi-grade filtering technology and precise measurement.

4. Auto control with high speed 485 or 232 communication interface,. It can store up several formulas, which can be changed according to customers' need.

5. Auto mixing/blending and packing, uniform blending, accurate and elaborate packing. No isolation happens during packing process. Scope of batching and blending can be adjusted in the scope of 10-100kg, it avoids the trouble that more percentage should be added in the production and the isolation phenomenon, cost is saved.

6. The actuating mechanism is driven by pneumatic machine, 2 grades material feeding, single measurement and accumulation measurement, fast production.

7. This control system is provided with functions of zero-position tracking, auto less tare, rough measurement and auto compensation on drop, auto measurement on over-momentum and alert on malfunction.

Item type	BPHB-6602	BPHB-6603	BPHB-6604	BPHB-6608
Packing (kg/bag)	10~15	10~50	10~50	25~50
Kinds of raw material	3~6	3~8	3~8	2~8
Packing precision	≤±0.2%	≤±0.2%	≤±0.2%	≤±0.2%
Batching precision	≤±0.2%	≤±0.2%	≤±0.2%	≤±0.2%
Capacity (t/h)	3	5	10	10~15
Power (kw)	15	15	15	15
Material	stainless steel (304 National Standard)	stainless steel (304 National Standard)	stainless steel (304 National Standard)	stainless steel (304 National Standard)
